Trailer & Road Train

trailer-road-train-intro

Part No.	No. Of Cores	Cable Dia. (mm)	Length (metres)	Colour	Amps	Conductor cross section (mm2)	Strand No./Dia.	NZ Ref.
5 Core Trailer & Road Train Cable
5852-30FTC	5	2mm	30	Red, Green, Yellow, White, Brown	4 (10*)	0.50	19/0.19	-
5852-100FTC Economy Cable	5	2mm	100	As Above	4 (10*)	0.56	7/0.32	-
5852-30TC	5	2.5mm	30	As Above	5 (14.5*)	0.64	8/0.32	205
5852-100TC	5	2.5mm	100	As Above	5 (14.5*)	0.64	8/0.32	205
5853-30TC	5	3mm	30	As Above	10 (20*)	1.13	14/0.32	206
5853-100TC	5	3mm	100	As Above	10 (20*)	1.13	14/0.32	206
5854-30TC	5	4mm	30	As Above	15 (28*)	1.85	23/0.32	-
5854-100TC	5	4mm	100	As Above	15 (28*)	1.85	23/0.32	-
5856-30TC	5	6mm	30	As Above	55 (56*)	5.22	65/0.32	-
5856-100TC	5	6mm	100	As Above	55 (56*)	5.22	65/0.32	-

Part No.	No. Of Cores	Cable Dia. (mm)	Length (metres)	Colour	Amps	Conductor cross section (mm2)	Strand No./Dia.	NZ Ref.
7 Core Trailer & Road Train Cable
5872-30FTC	7	2mm	30	Red, Black, Green, Yellow Blue, White, Brown	4 (10*)	0.50	19/0.19	-
5872-30TC	7	2.5mm	30	As Above	5 (14.5*)	0.64	8/0.32	-
5872-100TC	7	2.5mm	100	As Above	5 (14.5*)	0.64	8/0.32	-
5873-30TC	7	3mm	30	As Above	10 (20*)	1.13	14/0.32	207
5873-100TC	7	3mm	100	As Above	10 (20*)	1.13	14/0.32	207
5874-30TC	7	4mm	30	As Above	15 (28*)	1.85	23/0.32	-
5874-100TC	7	4mm	100	As Above	15 (28*)	1.85	23/0.32	-
5876-30TC	7	6mm	30	As Above	55 (56*)	5.22	65/0.32	-
5876-100TC	7	6mm	100	As Above	55 (56*)	5.22	65/0.32	-
